Viair Dual 380C Air Compressor Kit
HomeStore

Viair Dual 380C Air Compressor Kit

Viair Dual 380C Air Compressor Kit

TWICE AS NICE.

Check out the Viair 380C dual pack. These two reliable and high-performing compressors are capable of reaching 200 PSI, making them ideal for pneumatic applications like tire inflation, air lockers, and air suspension. With a single Viair 380C, you can support up to 5 gallons of air, and with two, you can double your refill speeds. The Viair 380C has a 100% duty cycle at 100 PSI and 50% at 200 PSI, making it a great option for entry-level constant duty compressors. Upgrade your system and experience lightning-fast recharge times, recharging a 2.5-gallon tank from 165-200 PSI in only 53 seconds and recharging a 5-gallon tank from 165-200 PSI in just over 2 minutes.

This compressor does come with the option to add our 40 Amp Dual Air Compressor Wiring Kit to it as well!

  • Permanent Magnetic Motor
  • Oil-less Design
  • High-Performance PTFE Piston Ring
  • Stainless Steel Valves
  • Moisture & Dirt Resistant
  • Gearless Direct Drive Motor
  • Anodized Aluminum Alloy Cylinder
  • Automatic Reset Thermal Overload Protector
  • Mounting Plates with Vibration Isolators
  • Stainless Steel 1/4" Braided Leader Hose
  • Remote Mountable Intake Filter Assembly
  • Insulated Wiring with Connectors

Note: Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque for 1/8″ is 10 ~ 11 ft. lbs. Recommended torque for 1/4″ and 3/8″ is 12 ~ 15 ft. lbs.

PSI CFM A BAR LPM A
0 2.54 28 0 72.0 28
10 2.42 29 1.0 67.0 30
20 2.30 31 2.0 61.7 33
30 2.17 33 3.0 57.5 34
40 2.07 34 4.0 53.5 36
50 1.95 35 5.0 49.8 37
60 1.87 36 6.0 46.4 39
70 1.78 37 7.0 43.3 41
80 1.70 38 8.0 40.3 43
90 1.61 39 9.0 37.2 44
100 1.54 41 10.0 34.5 42
110 1.46 42 11.0 31.8 41
120 1.40 43 12.0 29.2 40
130 1.32 44 13.0 26.6 38
140 1.25 43 14.0 23.7 37
150 1.19 42
160 1.12 41
170 1.06 40
180 0.99 39
190 0.93 38
200 0.86 37

 * Supply Voltage: 13.8 Volts

2.5 GALLON TANK FILL RATE
0 to 200 PSI 3 min. 13 sec. (± 10 sec.)
165 to 200 PSI 53 sec. (± 05 sec.)
5.0 GALLON TANK FILL RATE
0 to 200 PSI 7 min. 11 sec. (± 15 sec.)
165 to 200 PSI 2 min. 06 sec. (± 10 sec.)

* Supply Voltage: 13.8 Volts

  • Dual Viair 380C Air Compressor
  • 1/4" NPT Stainless & Black Braided Leader Hose & Check Valve
  • Remote Mount Two-Stage Air Filter
  • Dual Viair 40 Amp Relays
  • Viair 110/145 PSI Pressure Switch
  • Installation Instructions
  • Replacement Filter Elements
  • 1 Year ManufactureR's Defect Warranty
  • Mounting Hardware
Part Number DC-380, DC-380C, DC-380K
Manufacturers Part Number 38002 / 38003 / 38036
Voltage 12 Volts DC
Combined Max Amperage 44 Amps
Maximum Duty Cycle 100% @ 100 PSI
Maximum Pressure 150 PSI
Max Tank Size 10 Gallons
CFM @ 0 PSI 2.54 CFM
Each Length 9″ (228.6 mm)
Each Width 4″ (101.6 mm)
Each Height 6.75″ (171.5 mm)
Each Weight 6.95 lb (3.15 Kg)
  • Money-Back Guarantee/Refund Policy
    All merchandise unless otherwise indicated may be returned within 30 days from the shipment arrival date for a refund. A Returned Merchandise Authorization (RMA) number is required for all returns. A 15% restocking fee may apply. Additional deductions may be made to reflect the products current market value. These terms apply to all refunds. Most products are shipped with a refund/replacement guarantee period unless otherwise noted in the product listing. Customers must inform HornBlasters.com of any order discrepancy within 7 days from the invoice date so that we may investigate and resolve the situation accordingly.
  • Warranty
    This product is backed by Viair's 1-year manufacturer's warranty! All Warranty claims for Viair products must be handled directly through Viair after 30 days. They can be reached at 1-949-585-0011.
  • HornBlasters.com Satisfaction Guarantee
    HornBlasters.com offers our customers a 30-day satisfaction replacement or refund guarantee on all purchases, except when otherwise noted in the product listing.
  • Cross-Shipments
    HornBlasters.com will not cross-ship returned merchandise.
  • Physical Damage Policy
    Physical damage to any product purchased at HornBlasters.com will effectively void warranty coverage. Physical damage includes but is not limited to improper handling and/or any other type of damage sustained by irregular usage.
